BLE5.0 nRF52832 Module

BLE5.0 nRF52832 Module
The BLE5.0 nRF52832 Module based on the Nrf52832 from Nordic Semiconductor. The module with an ARM Cortex M4F 32 bit processor, support Bluetooth 4.2 and 5.0 protocols. This module breakout all the IO PIN of the Nrf52832. Making you more quickly into the Bluetooth smart application and remove the worries.


  • System on Module(SOM) base on Nordic nRF52832
  • Bluetooth Low Energy/ANT/2.4GHz Proprietary Multi-protocol support
  • Complete Bluetooth Low Energy stack/profiles solution (Bluetooth 4.x and Higher)
  • ARM Cortex M4F 32 bit processor,512kB flash memory ,64kB RAM
  • Breakout all IO PIN
  • 12-bit/200KSPS ADC ,PWM ,SPI Master/Slave(8Mbps)
  • Two 2-wire Master/Slave (I2 Compatible)
  • I2S audio interface ,PDM audio interface
  • UART(w/CTS/RTS and DMA)
  • 3×4 – channel PWMs
  • 20 channel CPU independent Programmable Peripheral Interconnect(PPI)
  • Quadrature Demodulator(QDEC)
  • 128-bit AES HW encryption
  • 5×32bit Timer, 3×24bit Real Timer Counters(RTC),Watchdog Timer
  • Internal RC Oscillator 32.768kHz(±250ppm)
  • Package List:

  • 1 x BLE5.0 nRF52832 Module
  • Documents:

    Write a review

    Note: HTML is not translated!
        Bad           Good

    • Product Code: MCB52832M
    • Availability: In Stock
    • $6.50
    • 51 or more $6.20
