STM8 Minimum System Development Board- STM8S103F3P6

STM8 Minimum System Development Board- STM8S103F3P6
This board is low cost Minimum System Development Board for ARM Microcontroller – STM32F103C8T6. Board is suitable for learners that want to learn STM32 microcontroller with ARM Coretex-M3 32-bit core.

Features:

  • On-board Mini USB interface, you can give the board power supply and USB communication
  • On-board test indicator LED
  • On-board reset button and power indicator LED
  • On-board 100ma 3.3V Regulator
  • All GPIO are led out and the names of the pins are marked
  • After soldering the headers, you can directly plug the board onto the breadboard
  • CPU: STM32F103C8T6
  • Core: ARM 32 Cortex-M3 CPU
  • Debug mode: SWD (can be programmed with ST-LINK V2)
  • CPU Internal Maximum Clock: 72MHz
  • External Clock Source: 8MHz crystal
  • 64K flash memory, 20K SRAM
  • 2.0-3.6V power, I/O
  • Package List:

  • 1 x STM32 Minimum System Development Board
  • Documents:

  • Datasheet
